Secure / fasten cables neatly against the wall and ensure it is not hanging from device hdmi ports which can cause equipment damage.Įnsure all HDMI / DVI Cables and Equipment used are HDMI v1.3, HDCP 1.2 capable. Even if the HDMI cable fits securely please ensure that there are no sharp bends of the cable or the cable is causing the hdmi port to bend. There are often handshake issues simply due to a poor connection. There is a recommended power-on sequence below if you regularly power cycle your equipment. Since we do power-off displays and source devices most issues occur when these devices are powered on again to re-negotiate the HDCP handshake between source and display. HDCP handshake issues rarely occur when all sources, hdmi distribution equipment and displays are always powered on 24×7. HDMI / HDCP Handshaking issues = Problems with Video or Audio on your display (Mostly caused by an encryption named High-bandwidth Digital Content Protection (HDCP). HDMI Handshake issues occur when the LCD or source does not accept the keys from HDMI Distribution equipment. Each device features a unique set of keys which need to be accepted by the display and source before video/audio is displayed. HDMI handshake = The exchange of encrypted keys between the source / player and the LCD and HDMI Distribution equipment. In general digital receivers and amplifiers must support the HDCP Repeater bit if used between source and display together with HDMI Extenders, Splitters or Switches. multiple inputs to 1 monitor-out HDMI port). HDMI Distribution Equipment = HDMI / DVI Splitters, HDMI / DVI Switches, HDMI / DVI Extenders, HDMI/DVI Converters or any equipment on the network between the source and display (Amplifiers / digital receivers included if used between source and display as HDMI switch e.g.
Interface / Connector used to connect source devices and displays with each other to provide high bandwidth video and audio (Resolutions up to 2560×1600 75hz / 1600p / Quad-HD + 8-Channel Audio, Dolby TrueHD, DTS-HD Master Audio). HDMI = High-Definition Multimedia Interface. Wait 10 seconds or more after equipment was powered off to be powered on again. Power cycle = Power off / Power on equipment (At the wall socket since some LCD’s will still provide a low voltage to HDMI Distribution Equipment via the HDMI port if it is changed to standby mode via remote and HDMI Distribution Equipment will never power cycle completely if still powered via HDMI port). Source Device = Any Blu-ray Player, DVD Player, Gaming Console (PS3, Xbox 360), Apple TV, HD PVR or any device with a DVI, HDMI or DisplayPort Output. Expressions used in documentĭisplay = Any LCD / Plasma / Projector or any other screen with a DVI, HDMI or DisplayPort input Please see the best practices HDMI installation guidelines under our technical documentation. Only use the Switched Mode Power supply supplied with the HDMI Equipment since replacing the power adapter might damage your equipment if incorrect voltage is supplied to the equipment. You will damage your equipment and the HDMI Distribution equipment while hot-plugging cables which will not be replaced under the 1 year manufacturers warranty and your HDTV or Display Warranty if port damaged will also be void. HDMI cables carries a low DC voltage while connected. Warning!!: Never connect and disconnect HDMI cables and equipment while your devices are powered on (hot plugging cables). Choosing the right HDMI Cables, HDMI over Ethernet, HDMI over Network UTP/STP Bandwidth Required.What is HDBASET Technology and HDBASET V2.0 / V2.1 Technology.OVHD, DSTV Explora Installation Diagram / Sample Distribution diagram to multiple displays.Optic Fiber Cables – Difference between UPC vs APC, Single Mode vs MultiMode and SFP Compatibility.HDMI v2.1 Specifications including HDMI v2.0, HDMI v1.4 and older.HDMI Best Practices Installation Guidelines and Recommendations.HDCP Error / HDMI Handshake (Picture Sync) Troubleshooting and Guidelines.Ethernet Networking Cable : CAT5 vs Cat6 vs Cat7 vs Cat8 : What is the Difference ? Wiring and Specifications.DSTV XtraView Installation & Frequencies (DSTV User Bands) for Multichoice Explora/HDPVR and other decoders.Home Entertainment Wiring Diagram – HDMI to AV, HDMI Splitter, HDMI Extender, HDMI to VGA, VGA to HDMI.2.4Ghz vs 5Ghz Wifi Bands & Wifi 4 vs Wifi 5 vs Wifi 6 Technologies.Technical Info | Wiring Diagrams Menu Toggle.
